Heavy-Duty Automated Winding Solutions for Industrial Motors

Engineering Robust Production Systems for Continuous-Duty Applications

As skilled labor availability decreases, transitioning from manual coil insertion to automated production is critical. However, large stator dimensions combined with high slot-fill requirements present extreme mechanical and precision challenges that standard equipment simply cannot endure.

What Makes the Automation Upgrade for High-fill-rate Stator Winding in Large Motors Such a Challenge?

High Slot-Fill Constraints

Heavy Wire Stiffness

Machine Deflection Risks

Robust Engineering for Large-Scale Motor Production

Heavy-Duty Machine Architecture

GMW equipment is built with exceptional structural rigidity to absorb the extreme forces generated during the winding and insertion of heavy-gauge wires, ensuring absolute positional accuracy and operational stability without machine deflection.

Automated High Slot-Fill Insertion

We engineer precise tooling and guided insertion profiles that safely pack maximum copper into large industrial stators. This minimizes insulation damage while achieving the superior efficiency and power density required by modern industrial standards.

Seamless Transition from Manual Processes

Whether automating for the first time or upgrading existing lines, our scalable systems reduce dependency on manual labor, drastically increasing throughput and process repeatability for demanding industrial applications.

Typical Industrial Motor Specifications Supported

Parameter	Typical Range
Stator Outer Diameter	120-300 mm
Stack Height	50-200 mm
Wire Diameter	0.6-1.2 mm
Motor Type	Induction Motor / PMSM
Applications	Industrial equipment, compressors, heavy-duty motors
